99.95% W Tungsten Boat Thermal Evaporation High Melting Point
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Tungsten Thermal Evaporation Boat | Size | Customized According To Customer Needs |
|---|---|---|---|
| Material | Pure Tungsten | Grade | W1 |
| Feature | High Melting Point | Purity | 99.95% W |
| Highlight | Thermal Evaporation Tungsten Boat,High Melting Point Tungsten Boat |
||
Product Description
99.95% W Tungsten Thermal Evaporation Boat High Melting Point
Thermal Evaporation Boat Application:
Suitable for sintering boats in precision ceramics and cemented carbide industry.
Surface Treatment of Thermal Evaporation Boat :
Black surface, as machined
Alkali washing surface, by chemically cleaning to remove all the lubricants and oxides.
Ground surface, by centerless grinding for assurance of precise dimensions
Parameters
|
Products Name |
99.95% W Tungsten Thermal Evaporation Boat High Melting Point |
|||
|
Size |
Customized according to customer needs |
|||
|
Material |
pure tungsten |
|||
|
Grade |
W1 |
|||
|
Density |
19.2g/cm3 |
|||
|
Surface |
polished |
|||
|
Application |
Evaporation boat |
|||
|
Atomic number |
74 |
|
CAS number |
7440-33-7 |
|
Atomic mass |
183.84 [g/mol] |
|
Melting point |
3420 °C |
|
Boiling point |
5555 °C |
|
Density at 20 °C |
19.25 [g/cm3] |
|
Crystal structure |
Body-centered cubic |
|
Coefficient of linear thermal expansion at 20 °C |
4.4 × 10-6 [m/(mK)] |
|
Thermal conductivity at 20 °C |
164 [W/(mK)] |
|
Specific heat at 20 °C |
0.13 [J/(gK)] |
|
Electrical conductivity at 20 °C |
18.2 × 106 [S/m] |
|
Specific electrical resistance at 20 °C |
0.055 [(Ωmm2)/m] |
Application
1. Metallizing, Electron-beam Spraying, sintering annealing in reducing atmosphere in electronics.
2. Military and light industries.
3. Evaporate small lengths of wire or evaporate materials.
4. A tungsten boat is ideal for use in small evaporation systems.
5. Tungsten boat sources are used for the vacuum evaporation of materials.
