High Purity 99.95% Molybdenum Electrode Corrosion Resistance For Glass Melting
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Moly Electrode | Diameter (mm) | 10mm-100mm |
|---|---|---|---|
| Length (mm) | 4000 | Usage | Glass Melting |
| Material | Mo | Purity | High Purity 99.95% |
| High Light | Molybdenum Electrode Glass Melting,Molybdenum Electrode Corrosion Resistance |
||
Product Description
High Purity 99.95% Molybdenum Moly Electrode For Glass Melting
Quick Details
1. Melting point of 2 620 °C (4 748 °F)
2. Anti-Oxidation Coating
3. Outstanding creep resistance
4. High dimensional stability
5. Excellent corrosion resistance
6. Good electrical and thermal conductivity
7. Outstanding purity
Parameters
| Diameter (mm) | Length (mm) |
| Ø2.0 – 30.0 | 4000 |
| Ø30.0 – 60.0 | 4000 |
| Ø60.0 – 100.0 | 4000 |
| Ø100.0 – 200.0 | 4000 |
| Commodity | Diameter | Tolerance |
| Molybdenum Electrodes | 10mm-100mm | +/-(0.05-0.2)mm |
| Atomic number | 42 |
| CAS number | 7439-98-7 |
| Atomic mass | 95.94 [g/mol] |
| Melting point | 2620 °C |
| Boiling point | 4639 °C |
| Density at 20 °C | 10.22 [g/cm³] |
| Crystal structure | Body-centered cubic |
| Coefficient of linear thermal expansion at 20 °C | 5.2 × 10-6 [m/(mK)] |
| Thermal conductivity at 20 °C | 142 [W/(mK)] |
| Specific heat at 20 °C | 0.25 [J/(gK)] |
| Electrical conductivity at 20 °C | 17.9 × 106 [S/m] |
| Specific electrical resistance at 20 °C | 0.056 [(Ωmm2)/m] |
Application
Molybdenum electrodes can be used in glass melting furnaces producing high-quality glass and refractory glass fiber industry. Our electrodes are energy efficiency, have long service life, and environmentally friendly. Molybdenum has a better corrosion resistance than regular material in molten glass. If a tiny reaction happens, it’s colorless, which does not pollute glass products.
